AL-RCM2KW: 2 kW rated output. Wholesale enquiries and installer projects. Contact KEZHUN on WhatsApp for pricing.
Functions
- MPPT solar charging
- Lithium battery BMS communication
- RS232 / RS485 communication interfaces
Specifications
| Model / configuration | AL-RCM2KW |
|---|---|
| Rated inverter output | 2 kW |
| Battery DC input voltage | 12 V |
| Maximum MPPT charge current | 100 A |
| Maximum AC charge current | 100 A |
| PV voltage range | 30–450 V |
| Source PV voltage label | Voc |
| Maximum PV input power | 3000 W |
| Maximum PV input current | 18 A |
| Parallel operation | No |
| Communication interfaces | RS232 / RS485 |
| Lithium BMS communication | Yes |
| Net weight | 4.5 kg |
| Gross weight | 5.5 kg |
| AC output voltage | 230 V |
| AC output frequency | 50 / 60 Hz |
Photo available on request.
Wholesale only. Single-unit retail orders are not supported. Contact us on WhatsApp to confirm MOQ and pricing.
Payment via XTransfer after quotation and order confirmation. Collection instructions are provided privately with the confirmed order.
Confirm the model, quantity, destination, installation requirements and any applicable AC voltage, frequency or plug configuration with the quotation.
