6 kW Vertical Stacked ESS – 10.24 kWh

SKU: VERTICAL-512200Residential ESS

Rated inverter output
6000 W
Storage capacity
10240 Wh
Battery operating voltage
40-58.4 V

Request quote Enquire on WhatsApp

Wholesale only · No single-unit retail orders. MOQ and pricing on WhatsApp.

Key features

  • Stacked inverter and battery modules
  • Expandable battery capacity
  • Pure sine wave output
  • AC / DC priority output
  • Built-in BMS
  • LED power display
Full specifications
Model / configurationVertical 512200
Rated inverter output6000 W
Battery chemistryLiFePO4
Battery operating voltage40-58.4 V
Storage capacity10240 Wh
Battery capacity100 Ah × 2 modules
Battery configuration1P16S × 2
Maximum charge current100 A
Maximum discharge current100 A
Inverter dimensions600 × 318 × 210 mm
Battery module dimensions600 × 430 × 210 mm
CommunicationsRS485 / CAN / RS232
IP ratingIP21
Net weight120.4 kg
Gross weight147.4 kg
Charge temperature0 to 50 °C
Discharge temperature-15 to 50 °C
Humidity0-90%
Maximum altitude3000 m

Confirm the model, quantity, destination, installation requirements and any applicable AC voltage, frequency or plug configuration with the quotation.

Documents & order information

Specifications & verification

Confirm model-specific specifications and any required certificates with KEZHUN before ordering.

Browse compliance & quality documents

Documents

Request the datasheet for this model. Confirm document availability and version with KEZHUN.

Request a Product Datasheet

Freight & Payment

Wholesale orders are confirmed by quotation. Ask for MOQ, product pricing, freight, any import charges, payment schedule and warranty terms in writing before ordering.

Payment via XTransfer after quotation and order confirmation. Collection instructions are provided privately with the confirmed order.
